Stretched LCD Panel

Stretched LCD panels, designed specifically for commercial advertising displays, offer flexibility for irregular shapes and diverse installation options.

What Is A
Stretched LCD Panel?

Stretched bar LCD module is an innovative OC panel technology that serves various long-shaped display devices and can be applied to various scenarios.

Compared to traditional LCD modules, they offer greater flexibility in terms of size and shape, meeting diverse commercial needs in retail displays, transportation signage, and outdoor advertising.

With their high-resolution image quality and enhanced color reproduction, they provide a superior visual experience for businesses.

Other Options

Full Specification

28 Inch
28.6 Inch
37 Inch
48 Inch

DV280FBM-NB1

Panel Type

a-Si TFT-LCD
Panel Composition

LCM
Panel Size

28"
Resolution

1920×360
Active Area

699.84 (W) × 131.22 (H) mm (A.A)
Outline Dimension

732 (W) × 165 (H) mm
Brightness

700 (Typ.)
Contrast Ratio

1200:1 (Typ.)
Operating Temp

0 ~ 50 °C
Storage Temp

-20 ~ 60 °C

DV286FBB-NV0

Panel Type

a-Si TFT-LCD
Form Factor

Flat Rectangle
Panel Size

28.6"
Resolution

1920×560
Active Area

698.4 (W) × 203.7 (H) mm (A.A)
Outline Dimension

708.4 (W) × 216.1 (H) mm
Brightness

500 (Typ.)
Contrast Ratio

1200:1 (Typ.)
Operating Temp

0 ~ 50 °C
Storage Temp

-20 ~ 60 °C

DV370FBM-N10

Panel Type

a-Si TFT-LCD
Panel Composition

LCM
Panel Size

37"
Resolution

1920×540
Active Area

899.712 (W) × 253.044 (H) mm (A.A)
Outline Dimension

914.9 (W) × 280.9 (H) mm
Brightness

700 (Typ.)
Contrast Ratio

1000:1 (Typ.)
Operating Temp

0 ~ 50 °C
Storage Temp

-20 ~ 60 °C

DV480FBM-N01

Panel Type

a-Si TFT-LCD
Panel Composition

LCM
Panel Size

48"
Resolution

3840×720
Active Area

1194.05 (W) × 223.884 (H) mm (A.A)
Outline Dimension

1217.85 (W) × 248.18 (H) mm
Brightness

1000 (Typ.)
Contrast Ratio

1000:1 (Typ.)
Operating Temp

0 ~ 50 °C
Storage Temp

-20 ~ 60 °C

Our Digital Screen Projects

Gallery

Relevant Documents

Specification

28" Stretched LCD Panel Parameter

28.6" Stretched LCD Panel Parameter

37" Stretched LCD Panel Parameter

48" Stretched LCD Panel Parameter

Why Choose Gomany

Quality Assurance

Quality is built into every step of our manufacturing process, with dedicated quality control specialists conducting rigorous inspections at each stage to ensure zero defects. This meticulous approach guarantees customers receive LCD screens of uncompromising quality and reliability.
Mature Experience

With extensive expertise in the commercial display sector, Gomany has successfully implemented large-scale digital signage deployments across diverse industries including retail, transportation, industrial applications, and smart city infrastructure. Our track record spans over 400,000 display installations since founding, demonstrating our capacity to deliver robust, industry-tailored visual communication solutions.
Project Evaluation

Our expert consulting team provides comprehensive project evaluation, delivering tailored optimization recommendations and actionable solutions - saving you valuable time and resources while maximizing your project's potential.
Delivery Guarantee

We guarantee reliable product delivery through our robust manufacturing system, currently maintaining a stable monthly output of 8,000+ commercial LCD digital display products Our precision-planned production scheduling ensures on-time, accurate deliveries to meet your project timelines without compromise.
Lifetime Technical Support

Upon delivery, you'll receive complete operational guidance for your equipment. Should any technical issues arise, our engineering team provides immediate remote assistance to ensure rapid resolution - minimizing downtime and maximizing your operational efficiency.
Support Customization

We provide a full range of customization services. You can add logos, choose colors, materials, and even customize functions to the products according to your needs. As long as you have requirements, we will try our best to tailor the most suitable solution for you.
3D Rendering Service

Our advanced 3D visualization solutions enable you to preview photorealistic display simulations before production, ensuring every detail meets your exact specifications. This empowers data-driven decision making and optimized planning for your projects.
Product Testing

Each LCD digital display device unit undergoes stringent pre-shipment testing, including environmental , mechanical vibration, and waterproof evaluations. This comprehensive validation process ensures stable operation in all conditions, delivering truly maintenance-free performance for your peace of mind.
Support Warranty

All display products come with 1-3 years of comprehensive warranty, with duration determined by your selected solution. Should you require extended coverage, our support team will customize an optimal protection plan tailored to your specific needs.
